1.Main features

It is used to wash 3-12mm and 35mm-thinner glass, with the horizontal structure, it is stable to transmit; stable performance with DELIXI contactor, push-button switches and pilot light. It adopts frequency stepless speed and is easy to operate as the button is concentrated on the operation table, the height of washing tank can be changed to meet the requirement of any glass thickness. Three groups of brushes assure the washing quality while two pairs of air knives assure the drying. Inspecting light is equipped to examine the glass quality.

Technical Parameters

Brand name                                                           MAG Machine

Model                                                                      BX1600

Power voltage:                                                     380V 50Hz

Max glass size                                                       1600*2000(mm)

Min glass size                                                        450*450(mm)

Transmission speed:                                            1-5m/min

Thickness of washing glass:                                3-12mm

Power rate:                                                           11.33Kw

Overall dimmension                                             2700*2100*1200(mm)

Weight                                                                    1200kg
