Colorful PVC Welding Machine

Product Details

Main specification

WFH-2-4ME model welding and cleaning (seamless) welding machine for PVC window and door (plastic window and door) can clear welding beading at one time after finishing the welding, and can strictly control the size of welding seam; therefore, after welding of colorful section steel is finished, its surface welding creater looks perfect and top-grade, and its welding strength is higher than that of the original ones.

Main features

Model

WFH01

WFH-2-4ME

WFH-3-4ME

WFH-4-5ME

Brand Name

MAG MACHINE

Input voltage

220V 50/60Hz

220V 50/60Hz

220V 50/60Hz

220V 50/60Hz

Input power

1.5kw

2.5kw

3.0kw

4.5kw

Air pressure

0.6-0.8MPa

0.6-0.8MPa

0.6-0.8MPa

0.6-0.8MPa

Consumption

100L /min

180L /min

180L /min

180L /min

Welding range (mm)



420-3500

420-3500

420-4500

Welding height

10-120mm

10-120mm

10-120mm

10-120mm

Welding width

≤120mm

≤120 mm

≤120 mm

≤120 mm

Welding mullion width

≤110mm

≤110 mm

≤110 mm

≤110 mm

Overall dimension(cm)

10-120mm

10-120mm

10-120mm

10-120mm

Weight

800kgs

2500kgs

3000kgs

3500kgs

Humidity

<80% (no dew)

Temperature

-5~+40

Welding methods

Weld window frame
Weld window-support
Weld from free angle
Weld from 180 angle
Weld profile materials of different heights



Concentrate, Professional, Every step

◆ Strong mechanical processing strength ensures the perfect quality of each part.
◆ Global strength partners, purchasing real high-end accessories.
◆ Skilled workers ensure accurate assembly and commissioning of each piece of equipment.
◆ Passed strict inspection, the whole wooden box packaging.
◆ Perfect logistics ensures that the machines supply the transportation in time.
◆ Professional service team to ensure pre-sale, post-sale worry-free.
